LE12J
TYPE Two way active monitor
BANDWIDTH 65Hz-18kHz ±3dB
DRIVERS 12” (305mm) dia. 3” (75mm) voice coil
1.4” (35mm) exit compression driver
RATED POWER LF: 300W AES, 1200W peak.
HF: 75W AES, 300W peak.
RECOMMENDED AMPLIFIER 500-700W into 4 ohms
SENSITIVITY LF: 98dB / HF: 106dB
LF: 121dB continuous, 127dB peak
HF: 124dB continuous 130 dB peak
IMPEDANCE LF: 8 ohms nominal
HF: 16 ohms nominal
CROSSOVER 1300Hz
DISPERSION 50-100 degs horizontal
(differential dispersion),
70 degs vertical
ENCLOSURE 38 litres
CONNECTORS 2 x Speakon
DIMENSIONS (W) 607mm x (H) 343mm x (D) 434mm
(W) 23.9ins x (H) 13.5ins x (D) 17.1ins
WEIGHT 25.7kg (57lbs)
SHIPPING DIMENSIONS (W) 710mm x (H) 420mm x (D) 510mm
(W) 28ins x (H) 16.5ins x (D) 20.1ins
SHIPPING WEIGHT 28kg (61.7lbs)
Martin Audio – LE SERIES
ENGLISH
8
