Pressing the CONT key selects either a 25A or 100mA test.
By pressing the SET UP key, the window for selecting the continuity pass limit is
displayed (see Fig. 6).
Fig. 6
Repeated pressing of the CONT key will cause the displayed value to increment
by 0.1Ω. Press PROCEED to fix the displayed value in the memory and return to
the set up menu. Press the MAN key to return to the SET UP menu without
storing the continuity pass limit.
c) Clear all Test Records
This allows all test records stored in the memory to be erased thereby making
space for new records.
Press the SET UP key. The display will show the setting options. Select all by
pressing the ALL key. The display will show a prompt to press the PROCEED key
to clear all records.
Press PROCEED to clear all records or MAN to return to set up menu with all
records retained unchanged.
d) Set Date
This has to be set up daily as follows:
Press the SET UP key. The display will show set up menu (see Fig. 3). Select the
The Print/Disp options are as follows:
a) All
Selecting this option by pressing the ALL key when the all option is displayed will
cause all the records stored to be output to the display/printer.
b) Appliance ID
Selecting this option by pressing the PROCEED key will result in the display
prompting for the I.D. of the appliance to be displayed. Enter the appliance I.D.
then press the PROCEED key. All test records stored in memory for that
appliance I.D. will then be output to the display/printer starting from the first
(oldest) record stored and include all the following records up to the most recent
record stored in memory.
c) Last
Selecting this option by pressing the PROCEED key will result in the last record
stored in memory to be displayed/printed.
d) From
Selecting this option by pressing the PROCEED key will result in the display
prompting for the low and high test number required to describe a block of
records which it is desired to view. The cursor will be positioned below the first
test number to be entered. Enter the lower number using the number keys then
press the PROCEED key to move the cursor to the high number. This will
automatically be set to the highest test number stored in memory. If a lower test
number is required for the top of the block this can be set in simply by overwriting
the displayed number. Pressing the PROCEED key outputs all the records in the
block. Pressing the SET UP key will clear the number that has been entered.
3.4 Testing Appliances
Two distinct methods of testing appliances are available with this appliance
tester.
3.4.1 Manual Mode
This mode can be entered any time the PAT is in its ready mode simply by
selecting the appropriate test key. With manual mode it is possible to carry out
individual tests on appliances without having to complete a full auto test. This can
be a useful aid to quickly establish that a repaired appliance is likely to pass an
auto test or just to establish that an earth bond has been correctly made for
example. The results obtained from manual tests are not stored in memory. The
manual tests which can be carried out with this PAT are as follows:
SET UP:- CONTINUITY
TEST LIMIT 0.10 ohm
SET UP:- CONTINUITY
TEST CURRENT 25 AMP
