16
Specifications*
System Frequency Response ............
Aiming............................
Sensitivity..........................
Impedance .........................
Crossover Frequency..................
High-Frequency Driver ................
Low-Frequency Driver.................
Binding Post Inputs ...................
Suitable Amplifier Range ..............
Maximum Power Handling .............
Weight............................
Overall Size (dia. x depth | h x w x d) ....
Required ceiling opening (including tolerance) ..
Projection from wall surface ............
Depth required behind wall surface.......
*Specifications are subject to change
without notice.
ML-60i
70–20,000 Hz ±2 dB
N/A
89dB
Compatible with 8 ohms
3,000 Hz
0.75" (1.9cm) titanium dome
6.5" (16.5cm) mineral-filled polypropylene cone
Spring clip accommodates wire up to 12AWG
15–80 Watts
50 Watts
3.5 lbs. each (1.6 kg)
8.8" x 3.4" (22.4 x 8.5cm)
7-7/8" (20cm)
0.2" (0.5cm)
3.2" (8cm)
