16
・
If the water intake hose and extra water hose are left
connected, the packing may be damaged and leaks
may occur. Be sure to remove and store them.
・
Store the regulator control spring with no load
applied. To maintain the correct pressure indication,
return the grip to “0”, and the handle to the “Start”
position.
・
To prevent damages due to freezing in winter season,
remove water completely before storage. Specifically,
loosen the drain plug shown in the figure, drain water
from the inside of the machine, and perform cleaning,
maintenance, and storage.
・
Before replacing oil, make sure that this machine has
stopped.
・
For the first time replacement, replace oil after 50
hours have elapsed. Then, replace every 100 hours.
Since oil degrades, replace oil at least once a year
(SAE 10W-30 or equivalent) even if the 50 or 100
hours mark has not passed.
Remove oil after oil cools down.
