18
DETAILED MAINTENANCE AND REPAIR
Turn power “OFF” before conducting any maintenance procedures.
HOW TO REPLACE FRONT WHEELS & REAR LEFT WHEEL
Tools Required: Flat head Screwdriver
(not included)
hcnerW xoB mm71
(included)
1. Remove the Axle Cap with a flat head screwdriver.
2. Remove the M10 locknut with a 17mm socket wrench.
3. Remove the Ø12 washer.
4. Remove the wheel, then replace with a new one and make sure the Ø12 bushing
sits inside the wheel.
5. Remount the Ø12 washer, M10 locknut and securely tighten the wheel; then
re-insert the axle cap.
