MASINGO Ostinato M7 - Rear Panel Connections

8
[Quick Start Guide]
MIC 2MIC
LINE IN LINE OUT
MICRO-SD
USB
POWER
DC 5V
MIC 1
1. 6.5 mm Mic One Input
2. 6.5 mm Mic Two Input
3. 3.5 mm AUX Line in
4. 3.5 mm AUX Line out
5. MicroSD Slot
6. USB Slot
7. Power Input
8. Charging Indicator Light
9. FM Antenna
2345 6789
Function Board Back
