Troubleshooting
PROBLEM POSSIBLE CAUSE(S) CORRECTIVE ACTION
Not Cutting Belt is slipping Tighten belt
Engine not running at full speed Move the throttle to fast
Vibrating Worn or damaged blade Replace blade
Technical Data
Technical Data
Model: Edger Petrol 950915
Engine Type: GC160 160cm
3
Engine Power: 2.38kW
Rated no-load speed: 2400/min
Petrol tank capacity: 1.8L
Oil tank capacity: 610mL
Cutting Depth MAX: 50mm
Adjustable Cutting Depth: +13 - -50mm
Cutting blade part number: 550442 Edger Blade
Weight: 30kg
Sound pressure level L
PA
at the operator position: 93dB(A)
Measured sound power level L
WA
: 97dB(A)
Guaranteed sound power level L
WA
(2000/14/EC): 98dB(A)
Technical Data
Model: Edger Petrol 950913
Engine Type: 3.5 I/C 127cm
3
Engine Power: 2.39kW
Rated no-load speed: 2800/min
Petrol tank capacity: 950mL
Oil tank capacity: 600mL
Cutting Depth MAX: 50mm
Adjustable Cutting Depth: +18 - -50mm
Cutting blade part number: 550442 Edger Blade
Weight: 30kg
Sound pressure level L
PA
at the operator position: 94dB(A)
Measured sound power level L
WA
: 98dB(A)
Guaranteed sound power level L
WA
(2000/14/EC): 98dB(A)
