Mastech HY1503D User Manual

Storage environment: Temperature:-10
0
C to 70
0
C
Relative humidity: <70%
Table 2-1
Model Max. Voltage Max. Current Fuse Rating Dimension (mm)
HY1503D 15V 3A 5A/250V 270×128×145
HY1803D 20V 3A 5A/250V 270×128×145
GPS-1850D 20V 5A 5A/250V 270×128×145
HY3003D* 30V 3A 5A/250V 270×128×145
HY3005D* 30V 5A 5A/250V 270×128×145
HY3006D 30V 6A 5A/250V 270×128×145
HY6003D 60V 3A 5A/250V 270×128×145
HY3003DX 30V 3A 5A/250V 270×128×145
HY3005DX 30V 5A 5A/250V 270×128×145
HY5003D 50V 3A 5A/250V 270×128×145
HY5005D 50V 5A 5A/250V 270×128×145
*GPS-3050D and HY3005D are identical, while HY3003D and GPS-3030D are identical.
2-2 Front Panel Descriptions
(1) Digital ammeter: displays the actual output; this equates to the set value if in CC mode.

Mastech HY1503D Specifications

General

Brand	Mastech
Model	HY1503D
Category	Power Supply
Language	English
