Mastech MS7220 User Manual

HYS005213
Simulating a Thermocouple
① OUTPUT.
② Shows TC type select.
③ Press to select ON or OFF.
④ Press to select TC type or mV.
⑤ Press so that OUTPUT is on the display.
⑥ Press to step up/down 10°or 1mV.
⑦ Press to toggle ℃ or ℉
⑧ Press to scroll up/down 0.1°or 0.01mV.
Hold down to scroll faster.
⑨ TC wire and mini plug of same type as selected.
MS7220
MASTECH
R
INPUT
OUTPUT
TC
TYPE
C/ F
30V MAX
INPUT
OUTPUT
TC
TYPE K
OUTPUT
TC
1
2
3
4
5
6
7
8
9
