MS8218 True RMS Multimeter
Introduction to the Meter
(8) SELECT key
When setting the rotary switch to a measurement function, the meter will enter its first measurement mode, while pressing the
SELECT key it is possible to select the second or the third measurement mode. However, there is only one for the diode and
Capacitance measurements.
(9)WAKE key
After the meter being automatically shutdown, by pressing the WAKE key it can be woken up to resume the measurement. In
case of pressing POWER switch(for putting on the unit) and WAKE key simultaneously, the meter will in a continuously
working state without the automatic shutdown function.
(10)MAX/MIN key
Press MAX/MIN key to enter the record state for the maximum and minimum value and simultaneously display the maximum
value. By pressing this key again it will be possible to display the minimum value and the maximum value-minimum value.
When releasing the key after pressing it for two seconds, the maximum and minimum record state will be exited. Pressing this
key will be void during frequency
、
diode measurement.
(11)REL
△
key
By pressing REL
△
to enter the relative measurement state, the meter will remember the value measured at the time when
pressing the key(it is called the initial value), and after that the value displayed in the meter will be equivalent to the present
value – the initial value. By pressing the key again the relative measurement state will be exited. Pressing the key will be void
during the frequency and diode measurements.
6
