Master Audio
DSP206-608. Version 1.2 Apr 14 13
5.2 Output Menus
To access the Input Menus press the <Channel or Channel> key. Press Exit to finish
editing or again <Channel or Channel> to edit other channels.
The following menus are available for each output channel. Please note that by
default the inputs and outputs channels are linked in groups of two. The following
options are shown for the output group composed of Out1 and Out2
5.2.1 Input Gain
Adjust the gain of each output, using the rotary knob.
5.2.2 Mixer
Select the level to be routed from each input by turning the rotary knob. Select 0dB
for maximum level of an input. To disable one input, turn the rotary knob counter-
clockwise until “Off” is displayed. Push the rotary knob to select the next input.
5.2.3 Delay
Adjust the delay by turning the rotary knob. Push this knob to switch the unit between
ms, ft or m.
5.2.4 Crossover
• Low Pass – First adjust the Low Pass Filter cut-off frequency. To switch it off, turn
the rotary knob clockwise until frequency reaches 20 kHz.
Second, press the rotary knob and select from the available types and slopes:
Type: Butterworth, Slopes: 6dB, 12dB, 18dB or 24dB
Type: Bessel. Slopes: 6dB, 12dB, 18dB or 24dB
Type: Linkwitz-Riley. Slope: 12dB or 24dB
