DSP206-608. Version 1.2 Apr 14 23
9 SPECIFICATIONS
DSP206 DSP608
Analog Inputs
Number 2 4
Input Impedance >10 kOhms
Maximum Level +23 dBu
Type Electronically balanced
Digital inputs
No. of channels / connectors - 2 / 1 XLR3
Type - AES/EBU or S/PDIF
Accepted formats - 16 or 24 bit;
44.1, 48, 88.2 or 96kHz
Analog Outputs
Number 6 8
Maximum Level +12 dBu
Type Impedance Matched
Audio Performance
Frequency Response 20Hz to 20kHz (+/- 0.5dB)
Input Dynamic Range 110 dB (unweighted) 118 dB (unweighted)
Crosstalk < -80 dB < -85 dB
Distortion 0.005% (A-weighted) 0.002% (A-weighted)
Digital Audio Performance
Processing 64-bit
Analog Converters High Performance 24-bit
Sampling Rate 48 kHz 65 kHz
Propagation Delay 1.32 ms 1 ms
Front Panel Controls
Display 2 x 16 Character Blue Backlit LCD
Level Meters Per I/O: Signal Present, -6dB; Limiter, Clip
Buttons Illuminated Mute Controls, Menu Controls
Dial Encoder Rotary Thumb Wheel
Connectors
Analog Audio 3-pin XLR Pin 1: shield 2: live (+) 3: return (-)
Digital Audio (AES/EBU) - 3-pin XLR
USB Type B (on front panel)
Ethernet - RJ-45
Power Standard IEC Socket
General
Power 200 to 240 VAC (50 / 60 Hz)
Dimensions (H x W x D) 1U 19” Rack 44 x 483 x 165 mm
Weight 2.3kg 2.5kg
System Parameters
No. of Programs 50 80
Program Names 16 character length
Security Lock Password Lock/Unlock
Note: Specifications subject to change without notice
