Master audio DSP206 - Quick Reference

Master Audio
DSP206-608. Version 1.2 Apr 14 21
7 QUICK REFERENCE
Menu
Function
Channel
Parame
ter
Value Units
Gain I / O Gain -48 to +12; Step: 0.25 dB
Source
(608 only)
Inputs Source
Analog / AES Channel A / AES Channel
B / AES Mono Sum / AES Stereo
Mixer Outputs
Input
1/2/3/4
-48 to 0; Step: 0.25 dB
Delay I / O Delay 0 to 2000; Step depends on range ms
Freq. 20 to 20000; Step depends on range Hz
Type
BUT 6dB / BES 6dB / BUT12 dB / BES
12 dB / LR 12 dB / BUT 18 dB / BES
18dB / BUT 24dB / BES24 dB / LR 24dB
LowPass /
High Pass
I / O
Enabled On / Off
Freq. 20 to 20000; Step depends on range Hz
Gain -12 to 12; Step: 0.25 dB
Q 0.2 to 25; Step: 0.1
Type
Bell / Notch / High Shelf / Low Shelf /
Allpass/ Band Pass/ High Pass/ Low
Pass
PEQ 1 to
PEQ 10
I / O
Enabled On / Off
Thr. -48 to +24; Step: 0.25 dBu
Att. 1 to 10000; Step: 1 ms
Hold 1 to 10000; Step: 1 ms
Release 1 to 10000; Step: 1 ms
Ratio 1.2:1 to 25:1
Compres-
sor
I / O
Makeup
Gain
-12 to +12; Step: 0.25 dB
Thr. -48 to +24; Step: 0.25 dBu
Limiter Input
Rel. 10 to 100; Step: 1 dB/s
Thr. -48 to +12; Step: 0.25 dBu
Limiter Output
Rel. 10 to 100; Step: 1 dB/s
Phase Output Phase Normal / Inverted
Link I / O Link Off / On
