MASTER-BILT PART LIST
The table below gives Master-Bilt part numbers. Use this chart when ordering replacement parts for your BMG/TMG
cabinets. Always Advise Cabinet Serial Number When Ordering Parts
Description BMG/TMG-27 BMG/TMG-48 BMG/TMG-52 BMG/TMG-74 BMG/TMG-80
Accumulator 09-00812 09-00813 09-00813 09-00812 09-00812
Ballast 23-01709 23-01704 23-01704 23-01704 23-01704
Bulb 23-01575 23-01575 23-01575 23-01575 23-01575
Lamp Holder 23-50562 23-50562 23-50562 23-50562 23-50562
Capillary Tube 11-01450 11-01450 11-01450 11-01450 11-01450
Condensate Heater “B” 17-00380
Condensate Heater “T” 17-00421 17-00421 17-00421 17-00421 17-00421
Compressor “B” 03-50330 03-50330 03-50330 03-14901 03-14901
Compressor “T” 03-50330 03-50330 03-50330 03-14901 03-14901
Condensing Coil “B” 07-13253 07-13253 07-13253 07-13296 07-13296
Condensing Coil “T”
Door-L.H. 31-02491 31-02492 31-02513 31-02492 31-02513
Door R.H. 31-02493 31-02514
Door Trim 29-01379 29-01379 29-01379 29-01379 29-01379
Drier 09-09309 09-09309 09-09309 09-09309 09-09307
Evaporator Coil 07-13293 07-13293 07-13293 07-13311 07-13311
Evaporator Fan Blade 15-13106 15-13106 15-13106 15-13106 15-13106
Evaporator Fan Guard 25-01324 25-01324 25-01324 25-01324 25-01324
Evaporator Fan Motor 13-13181 13-13181 13-13181 13-13181 13-13181
Female Door Plug 21-00568 21-00568 21-00568 21-00568 21-00568
Leg “T” 27-00558 27-00558 27-00558 27-00558 27-00558
Light Switch 19-13118 19-13118 19-13118 19-13118 19-13118
Pilaster 200I166XX 200-16156C 200-16156C 200-16156C 200-16156C
Power Cord “B” 120/15A
220/15A
21-01201 21-01201 21-01201
21-01513
21-01243
21-01513
21-01243
Power Cord “T” 120/15A
220/15A
21-01454 21-01454 21-01454
21-01454
21-01243
21-01454
21-01243
Electronic Control 19-14243 19-14243 19-14243 19-14243 19-14243
Temperature Sensor T1 19-14244 19-14244 19-14244 19-14244 19-14244
Temperature Sensor T2 19-14245 19-14245 19-14245 19-14245 19-14245
External Relay 19-14284 19-14284 19-14284 19-14284 19-14284
Thermometer 44-00963 44-00963 44-00963 44-00963 44-00963
14-1/16” X 45” 25-01296 25-01296
15-7/8” X 45” 25-01294 25-01294 25-01294
18-3/4” X 45” 25-01295 25-01295 25-01295 25-01295
Accessories
Description BMG/TMG-27 BMG/TMG-48 BMG/TMG-52 BMG/TMG-74 BMG/TMG-80
Baskets (Cantilever) A200-16600 A302-16600 A200-16600 A302-16600
Casters (4) 3” Diameter A200-11140 A200-11140 A200-11140
Casters (6) 3” Diameter A212-11140 A212-11140
Legs 6” A200-11170 A200-11170 A200-11170 A212-11170 A212-11170
Shelves (Cantilever) 33-01473 33-01474 33-01475 33-01474 33-01475
