1-1. FRONT VIEW (WCC-23SR)
1
6
2 3 4 5
7
8
9
w
er
0
q
o
p
iuy
t
2
1. FEATURE CHART
1 TOP GRILLE
2 GRILLE DECORATION
3 DOOR SWITCH
4 THERMOMETER
5 TOP HINGE ASSEMBLY
6 BRAND LOGO
7 DOOR LOCK
8 DOOR
9 DOOR HANDLE
10 SPRING BAR
11 BOTTOM HINGE ASSEMBLY
12 BOTTOM GRILLE ASSEMBLY
13 CASTER
14 SUCTION PIPE
15 CAPILLARY TUBE
16 CONDENSER ASSEMBLY
17 MOTOR
18 COMPRESSOR
19 SWITCH BOX
20 DRAIN PAN
- HINGE RIGHT
