HARDWARE PACK
1/4’’-20UNCx13 Screw
X 24
NO.10-24UNCx10 Screw
X 2
1/4’’-20UNC Nut
X 4
1/4’’-20UNC Screw
X 4
ST4.2x10 Tapping Screw
X 8
U Pin
X 1
1 3
4 5 6
KEY # DESCRIPTION PART NUMBER QUANTITY
1 1/4’’-20UNCx13 Screw 20120-13013-036 24
2 1/4’’-20UNC Screw G361-0002-9091 4
3 NO.10-24UNCx10 Screw 20124-10010-036 2
4 1/4’’-20UNC Nut 31220-13000-036 4
5 ST4.2x10 Tapping Screw 24200-42010-136 8
6 U Pin G350-0026-9000 1
TOOLS NEEDED FOR ASSEMBLY
• #2 Star-head screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
For correct hardware assembly, always position
the lock washer between the screw and the at
washer.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
Lock Washer
Flat Washer
Screw
BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface. Grill is heavy. Two people are recommended
to complete assembly.
