17” DRILL PRESS PARTS LIST
11
67 DP1700067 Pan Head Screw, M6*10 4
68 DP1700068 Flat Washer, ¢6 4
69 DP1700069 Lower Cover 1
70 DP1700070 Washer 1
71 DP1700071 Compression Spring 1
72 DP1700072 Pulley lower 1
73 DP1700073 Pulley Upper 1
74 DP1700074 Set Screw, M6*8L 1
75 DP1700075 Key, 4*4*80L 1
76 DP1700076 Motor, 475W/120V/60Hz/1725RPM 1
77 DP1700077 Flat Washer, ¢8*¢24*2 4
78 DP1700078 Hex Socket Head Screw, M8*16L 4
79 DP1700079 Power Cord, SJT16AWG/3C 105 1
80 DP1700080 Pan Head Screw, M5*10 2
81 DP1700081 Washer, ¢5 2
82 DP1700082 Pin, ¢6*28 2
83 DP1700083 Set Screw, M8*10 2
84 DP1700084 Set Screw, M5*8 2
85 DP1700085 Rack Retaining Ring 1
86 DP1700086 Table Bracket 1
87 DP1700087 Angle Label 1
88 DP1700088 Table 1
89 DP1700089 Table Bracket 1
90 DP1700090 Spring Washer, STW16 1
91 DP1700091 Hex Bolts, M16*50 1
92 DP1700092 Pin 1
93 DP1700093 Nut, M6 1
94 DP1700094 Lock Handle 1
95 DP1700095 Lock Handle 1
96 DP1700096 Worm 1
97 DP1700097 Retaining Ring, STW14 1
98 DP1700098 Handle 1
99 DP1700099 Handle Shaft 1
100 DP1700100 Worm Shaft 1
101 DP1700101 Worm Gear 1
102 DP1700102 Column, ¢72*¢67*1120 1
103 DP1700103 Rack 1
104 DP1700104 Hex Bolts, M10*35 4
105 DP1700105 Spring Washer, STW10 4
106 DP1700106 Base Column 1
107 DP1700107 Set Screw, M10*10 1
108 DP1700108 Base 1
109 DP1700109 Belt, 1045 (L)-VA-10(W)-36° 1
110 DP1700110 Dig -Readout Cover 1
111 DP1700111 Dig -Readout 1
112 DP1700112 Pan Head Screw, ST2.2*6.5 7
113 DP1700113 Speed Transducer 1
114 DP1700114 Speed Transducer Mount 1
115 DP1700115 Pan Head Screw, M3*6 1
116 DP1700116 Flat Washer, ¢4 1
117 DP1700117 Hex Socket Head Screw, M4*6 1
118 DP1700118 Transformer, 9V 1
119 DP1700119 Pan Head Screw, ST2.9*6.5 2
120 DP1700120 Pan Head Screw, M5*50 4
121 DP1700121 Switch, HY18 1
122 DP1700122 Tachometer wiring, 22AWGX2C 1
123 DP1700123 Switch 1
124 DP1700124 Led Switch Cover 1
125 DP1700125 Led Burner 1
126 DP1700126 Led light, 3.6V 1
127 DP1700127 Tube 1
128 DP1700128 Hex Nut, M8X1.0 1
129 DP1700129 LED wiring 1
130 DP1700130 Tube, ø35x30 1
131 DP1700131 Power Trans Plate 1
132 DP1700132 Wrench, 2.5*56*18 1
133 DP1700133 Wrench, 4*70*25 1
Key No. Part No. Part Name Qty Key No. Part No. Part Name Qty
1 DP1700001 Bearing, 51107 1
2 DP1700002 Spindle Pulley Upper 1
3 DP1700003 Spindle Pulley Lower 1
4 DP1700004 Magnet, Ø4×3 1
5 DP1700005 Sleeve 1
6 DP1700006 Key, 5x5x60L 1
7 DP1700007 Flat Washer, Ø6 1
8 DP1700008 Retaining Ring, Ø47 2
9 DP1700009 Bearing, 6204-2Z 2
10 DP1700010 Spacer 1
11 DP1700011 Retaining Ring, Ø20 1
12 DP1700012 Hex Socket Head Screw, M4*12 3
13 DP1700013 Pan Head Screw, M5*10 2
14 DP1700014 Flat Washer, ¢5 2
15 DP1700015 Knob 1
16 DP1700016 Bracket 1
17 DP1700017 Handle Shaft 1
18 DP1700018 Gear 2
19 DP1700019 Retaining Ring, Ø10 1
20 DP1200020 Lamp Switch, HY7 1
21 DP1700021 Worm Spring 1
22 DP1700022 Spring Cover 1
23 DP1700023 Hex Nut, M12*7 2
24 DP1700024 Gear Shaft 1
25 DP1700025 Key, 8*7*25L 1
26 DP1700026 Scale 1
27 DP1700027 Mount 1
28 DP1700028 Handle Cap 3
29 DP1700029 Handle Shaft 3
30 DP1700030 Handle Mount 1
31 DP1700031 Washer 1
32 DP1700032 Handle 1
33 DP1700033 Bolt 1
34 DP1700034 Pointer Label 2
35 DP1700035 Hex Socket Head Screw, M5*8 4
36 DP1700036 Pan Head Screw, M6*8 2
37 DP1700037 Flat Washer, ¢6.4*¢18*1.6 2
38 DP1700038 Nut 1
39 DP1700039 Nut Clamp 2
40 DP1700040 Clamp 1
41 DP1700041 Spring Washer, ¢6. 1
42 DP1700042 Speed Strut 1
43 DP1700043 Lock Seat 1
44 DP1700044 Hex Socket Head Screw, M6*16 1
45 DP1700045 Spacer 4
46 DP1700046 Ball, ¢3 18
47 DP1700047 Rib 1
48 DP1700048 Pin, ¢4X25 1
49 DP1700049 Hex Bolt, M6*12 1
50 DP1700050 Line Clamp 1
51 DP1700051 Spindle Box 1
52 DP1700052 Hex Nut, M10 1
53 DP1700053 Bolts 1
54 DP1700054 Retaining Ring, STW17 1
55 DP1700055 Bearing, 6203-2Z 1
56 DP1700056 Rubber Ring 1
57 DP1700057 Quill 1
58 DP1700058 Bearing, 6204-2Z 1
59 DP1700059 Spindle 1
60 DP1700060 Chuck, JT3-16mm 1
61 DP1700061 Chuck Key 1
62 DP1700062 Up Cover 1
63 DP1700063 Cover Latch 1
64 DP1700064 Pan Head Screw, ST4.2*10 2
65 DP1700065 Pan Head Screw, M4*10 4
66 DP1700066 Nut, M4 4
