Master-force 240-0066 - Default Chapter; Table of Contents

Unpacking
Install Column Support
Install the Table
Install the Drill Press Head
Install Handles
Install Chuck
Mount Drill Press
Power Source
Grounding Instructions
Extension Cords
Peak HP
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Variable Speed Range . . . . . . . . . . . . . . . 450-3000 RPM
Swing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17"
Chuck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5/8"
Spindle Travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1/2"
Table Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14” x 14”
Table Movement . . . . . . . . . . . . . . 45° Bevel, 360° Swivel
Overall Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65-1/2"
NET Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149 lbs
TABLE OF CONTENTS
PRODUCTION
SPECIFICATIONS
SAFETY RULES 1
Work Preparation
Work Area Preparation
Tool Maintenance
Tool Operation
ASSEMBLY 2
OPERATION 6
Safety Precautions
ON/OFF Switch
Adjust Table Height and Tilt Table
Adjust Speeds
Install Drill Bit
Adjust Drill Depth
MAINTENANCE 8
Cleaning
Lubrication
Keep Tool Repair
TROUBLESHOOTING 9
PARTS ILLUSTRATION & LIST 10
WARRANTY 12
SECTION PAGE
