UNPACKING
Refer to Figure 1.
• Check freight damage before opening the package. If
freight damage is noticed, file claim with the carrier
immediately.
• Check to ensure all parts are present. Contact
Customer Service Center at 1-877-393-7121
(M-F 9am – 5pm) immediately for missing parts.
• Locate the following parts before assembling:
A. Head Assembly
B. Table
C. Base
D. Column Assembly
E. Hex Bolts (4)
F. Spring Washers (4)
G. Feed Handles (3)
H. Chuck
I. Chuck Key
J. Crank Handle
K. Hex Wrenches (2)
ASSEMBLY
2
Figure 1 - Unpacking
