10
DESCRIPTION
KNOW YOUR DRILL/DRIVER (Fig.1)
PRODUCT SPECIFICATIONS
Motor 18Volt DC
Switch VSR (Variable Speed Reversible)
No Load Speed LO 0-300 / HI 0-1250 RPM
Clutch Positions 23 driving and 1 drilling
Chuck Capacity ½ inch
Max. torque 340 in. lbs
Driver Weight (without battery) 2LBS 10OZ
Battery Type Lithium-Ion
Battery Voltage 18Volt DC
Charger Input 120-Volts, 60 Hz AC only
Optimum Charging Temperature 41°F (5°C) -122°F (50°C)
Fig. 1
Torque adjustment ring
Keyless chuck
Variable-speed
trigger switch
LED Worklight
Powerdisplay button
Power display
Battery Pack
Direction of Rotation
Selector (Forward/
Center Lock/
Reverse)
Vents
Two-speed gearbox switch
Battery Release
Button
