11
WARNING! The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of
the project you are attempting. Before use of this product, familiarize yourself
with all operating features and safety rules.
ADJUSTABLE TORQUE
The drill/driver has 23 driving and 1 drilling positions
TWO-SPEED GEAR BOX
The two-speed gear box is designed for drilling or driving at LO or HI speeds.
A slide switch is located on top of your drill for selecting the appropriate
speed.
VARIABLE SPEED
The variable-speed trigger switch delivers higher speed with increased
pressure and lower speed with decreased trigger pressure.
KEYLESS CHUCK
The keyless chuck allows you to hand-tighten or release the drill bit in the
chuck jaws.
FORWARD/REVERSE/CENTER LOCK
The direction-of-rotation selector located above the trigger switch changes
the direction of bit rotation. Setting the trigger switch in the OFF (center lock)
position helps to reduce the possibility of accidental starting when not in use.
LED WORK LIGHT
Pressing the trigger switch illuminates the LED worklight, located on the front
of the Drill Driver. This feature provides extra light for increased visibility.
ASSEMBLY
WARNING! If any part is broken or missing, do not attempt to plug in the
power cord or operate the Drill/Driver until the broken or missing part is re-
placed. Failure to do so could result in possible serious injury.
WARNING! Do not attempt to modify this Drill/Driver or create accessories
not recommended for use with this Drill/Driver. Any such alteration or modifi-
cation is misuse and could result in a hazardous condition leading to possible
serious injury.
WARNING! To prevent accidental starting that could cause serious per-
sonal injury, always remove the battery pack from the Drill/Driver when as-
sembling parts.
