14
NATURAL GAS CONVERSION
12. Adjust the air shutters of main
burners and searing burner by loosening
the air shutter screws with the Phillips
screwdriver (DD).
Hardware Used
x 1
13. Remove the LP orifices of all the
main burners and the searing burner
with the orifice removal tool (CC) and
install the1.45mm orifices (FF).
Hardware Used
x 1
x 5
14. Remove the 6 screws at the back of
burner box with the Phillips head
screwdriver (DD). Detach the rotisserie
burner cover from the rear panel of burner
box.
During this step, keep a firm hold on the
rear burner cover. Otherwise, it will drop
and may break, possibly causing injury.
Hardware Used
x 1
Rear Burner
Cover
Phillips Head
Screwdriver
DD
Orifice
Removal Tool
CC
FF
1.45mm Orifice
Phillips Head
Screwdriver
DD
CC
FF
12
13
14
To Next Page
