Master Forge BG2294B-LB - Page 13

13
ASSEMBLY INSTRUCTIONS
Attach Side Burner assembly onto firebox.
13.
Attach two pcs Screws (AA)
into the upper
two holes on left side of firebox. Leave the
screw heads protruding approximately 0.2
inches.
Hardware Used
M6x16 mm Screw x2
AA
15. Attach Knob Bezel (K) to Side Burner
Assembly with two pcs Screws (DD).
Attach Knob (L) to Knob Bezel.
Hardware Used
M4x8 mm Screw x2
DD
5mm
AA
13
0.2 inches
14. Hang the Side Burner Assembly on the
two screws attached in the previous step.
Secure the Side Burner Assembly in place
using screws (AA
) and (BB) in the lower
three holes as shown.
Hardware Used
M6x16 mm Screw x2
M6x12 mm Screw x1
BB
AA
AA
14
BB
15
DD
K
L
