ASSEMBLY INSTRUCTIONS
7. Install cart leg mat
Install two cart leg mats (Q) into the
legs of right leg assembly (P) with a soft
hammer.
8. Install wheel
Slip wheel (U) and axle spacer
(AA) onto the wheel shaft (T).
Then insert the wheel shaft (T)
into the hole on legs of left leg
assembly (O). Slip another wheel
(U) onto the wheel shaft (T). Use
small wrench (CC) to tighten the
wheel (U) with axle washer (DD)
and M6 Nut (BB).
Hardware Used
x 1
AA
BB
Axle Spacer
M6 Nut
x 1
Small wrench
Axle Washer
x 1
x 1
CC
DD
