PARTS LIST
90,000 BTU/Hr
This list contains replaceable parts used in your heater. When ordering parts,
be sure to provide the correct model and serial numbers (from the model plate),
then the part number and description of the desired part.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 098511-61 Upper Shell 1
2 M15823-27 Screw, #10-16 x 1/2" 6
3 098512-07 Combustion Chamber 1
4 M16660 Photocell Bracket ▲ 1
5 HA3019 Photocell Assembly ▲ 1
6 M27417 Drain Plug 1
7 M10908-2 Screw, #6-32 x 3/8" ▲ 2
8 ** Burner Head Assembly 1
8-1 M23103 Nozzle 1
8-2 M10659-1 Nozzle Seal Washer 2
8-3 M10809-1 Nozzle Seal Spring 1
8-4 M8882 Nozzle Seal Sleeve 1
8-5 M50924-03 Burner Head Body 1
8-6 M50820-02 Barb Fitting 2
8-7 M10962-2 Spark Plug 1
9 M11084-27 Screw, #10-16 x 1/2" 3
10 M50814-06 Air Line 1
11 M51345-01 Fuel Line 1
12 097293-01 Fan 1
13 ** Motor and Pump Assembly 1
13-1 098783-02 Motor (230V/50Hz) 1
13-2 079975-01 Pump Body 1
13-3 FHPF3-2C Screw, #10-32 x 1/4" 2
13-4 M22009 Insert 1
13-5 M22456-1 Rotor 1
13-6 M50545 End Pump Cover 1
13-7 M12179 Intake Filter 1
13-8 M16545 End Filter Cover 1
13-9 M8940 Steel Ball (1/4" Dia.) 1
13-10 M10993-1 Pressure Relief Spring 1
13-11 M27694 Adjusting Screw 1
13-12 M22997 Plug 1
13-13 M12461-31 Screw, #10-32 x 1" 4
13-14 M12244-1 Output Filter 1
13-15 M12461-31 Screw, #10-32 x 1" 6
13-16 M11637 Lint Filter 1
13-17 M50820-02 Barb Fitting 1
13-18 M8643 Blade 4
14 M51114-01 Fan Guard 1
** Not available as an assembly, order parts separately.
▲ Optional extra parts to equip heater with flame-out control.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
15 M50631 Rubber Bumper 2
16 M12461-13 Screw, #8-32 x 1/4" 2
17 098138-02 Motor and Relay
Bracket Assembly 1
18 098136-04 Relay (motor start) 1
19 M16841-59 Wire Assembly (red 13 1/2") 1
20 NTC-4C Hex locknut 2
21 098557-07 Electronic Ignitor 1
22 M11084-29 Screw, #10-16 x 3/4" 2
23 099125-02 Terminal Board 1
24 099157-01 Rivet 1
25 M30865-02 Bushing 1
26 M30865-02 Bushing ▲ 1
27 M50104-02 Bushing 1
28 M30865-02 Bushing 1
29 M11084-27 Screw, #10-16 x 1/2" 6
30 098511-02 Lower Shell 1
31 M11271-8 Clip Nut 6
32 M15823-37 Screw, #8-18 x 1/4" 1
33 M51150-01 Fuel filter 1
34 M10990-3 Rubber Bushing 1
35 M51151-01 Fuel Line 1
36 098513-35 Fuel Tank 1
37 097702-01 Fuel Tank Cap 1
38 M16841-57 Wire Assembly (red 8 1/2") ▲ 1
39 097630-02 Flame-Out Control ▲ 1
40 M11143-1 Strain Relief Bushing 1
41 M15779-27 Power Cord 1
42 097661-02AB Side Cover 1
43 M11084-27 Screw, #10-16 x 1/2" 4
44 078918-01 Terminal Board Tab Cap 3
45 099177-01 Nut, 3/8-27 ▲ 1
PARTS AVAILABLE - NOT SHOWN
M18053 Filler Neck Screen 1
097650-01 Tradename Decal 1
098234-26 General Information Decal 1
