4110.607
15
15
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 4110.130 Handle 1
2 4103.842 Upper Shell 1
3 4109.590 Screw/Lockwasher, 1/2" 6
4 4100.638 Combustion Chamber 1
5 4100.671 Heat Shield 1
6 4160.602 Screw, #10-16 x 3/4" 2
7 4100.658 Photocell Bracket 1
8 4103.529 Screw, #6-32 x 3/8" 2
9 4103.552 Photocell Assembly 1
10 4110.563 Power Cord 1
11 ** Burner Strap Assembly 1
11-1 4110.092 Bracket 1
11-2 4109.526 Spark Plug 1
11-3 4100.664 Nozzle Adapter 1
11-4 4109.518 Nut, 14mm 1
11-5 4101.854 Nozzle 1
12 4105.287 Power Line RFI Filter 1
13 4101.151 Bushing 1
14 4150.528 Strain Relief Bushing 1
15 4103.651 Fan 1
16 4150.553 Rubber Bumper 2
17 4109.560 Motor Bracket 1
18 ** Motor and Pump Assembly 1
18-1 4106.098 Motor (230V/50Hz) 1
18-2 4101.532 Pump Body 1
18-3 4108.635 Insert 1
18-4 4103.441 Rotor 1
18-5 4109.724 End Pump Cover 1
18-6 4109.716 Lint Filter 1
18-7 4109.690 Intake Filter 1
18-8 4109.674 End Filter Cover 1
18-9 4108.528 Screw, #10-32 x 1" 3
18-10 4108.379 Steel Ball (1/4" Dia.) 1
18-11 4102.141 Pressure Relief Spring 1
18-12 4102.133 Adjusting Screw 1
18-13 4102.125 Plug 1
18-14 4109.708 Output Filter 1
18-15 4108.536 Screw, #10-32 x 1 1/8" 6
18-16 4100.661 Elbow, 90˚ (Barb Fitting) 1
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
**Not available as an assembly, order parts separately.
18-17 4101.666 Blade 4
18-18 4108.590 Screw, #10-32 x 3/4" 2
19 4103.685 Fan Guard 1
20 4108.486 Hex locknut 2
21 4101.152 Bushing (wires) 2
22 4110.124 Screw/Lockwasher, 1/2" 11
23 4105.195 Lower Shell 1
24 4104.170 Clip Nut 6
25 4110.133 Screw, #10-32 x 3/4" 1
26 4104.147 Rubber Airline 1
27 4109.567 Fuel Line 1
28 4110.195 Wire Assembly (red) 1
29 4100.541 Rubber Bushing 1
30 4110.135 Fuel Filter Assembly
31 4110.609 Electronic Ignitor 1
32 4108.510 Screw, #10-16 x 3/4" 2
33 4106.110 Terminal Board 1
34 4110.571 Rivet 1
35 4104.196 Flame-Out Control 1
36 4103.891 Fuel Tank Cap 1
37 4110.136 Fuel Tank 1
38 4104.175 Side Cover 1
39 4110.134 Nut, #10-32 3
40 4109.592 Hex Nut 1
41 4101.151 Bushing 1
42 4110.610 Vinyl Foam Gasket 1
43 4100.527 Lock Washer, #10 2
44 4110.165 Wire Assembly (black) 2
45 4106.179 ON/OFF Switch 1
46 4104.336 Switch Cover 1
PARTS AVAILABLE - NOT SHOWN
4105.292 Filler Neck Screen 1
4110.138 Tradename Decal 2
4110.196 Combustion Chamber
Ground Wire 1
4110.611 Decal Package 1
PARTS LIST
35,000 BTU/HR MODEL
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
PARTS LIST
35,000 Btu/Hr Model
