4110.607
17
17
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 4110.130 Handle 1
2 4103.842 Upper Shell 1
3 4109.590 Screw/Lockwasher, 1/2" 6
4 4104.090 Combustion Chamber 1
5 4160.602 Screw, #10-16 x 3/4" 2
6 4103.537 Photocell Bracket 1
7 4103.529 Screw, #6-32 x 3/8" 2
8 4110.564 Photocell Assembly 1
9 4110.536 Power Cord 1
10 ** Burner Head Assembly 1
10-1 4103.486 Nozzle 1
10-2 4100.525 Nozzle Seal Washer 2
10-3 4100.533 Nozzle Seal Spring 1
10-4 4101.622 Nozzle Seal Sleeve 1
10-5 4109.351 Burner Head Body 1
10-6 4106.071 Barb Fitting 2
10-7 4101.846 Spark Plug 1
11 4110.124 Screw/Lockwasher, 1/2" 12
12 4101.151 Bushing 1
13 4150.528 Strain Relief Bushing 1
14 4103.651 Fan 1
15 4150.553 Rubber Bumper 2
16 4110.165 Wire Assembly (black) 2
17 4109.560 Motor Bracket 1
18 ** Motor and Pump Assembly 1
18-1 4100.561 Motor with capacitor 1
18-2 4101.317 Pump Body 1
18-3 4108.635 Insert 1
18-4 4108.627 Rotor 1
18-5 4109.724 End Pump Cover 1
18-6 4109.716 Lint Filter 1
18-7 4109.690 Intake Filter 1
18-8 4109.674 End Filter Cover 1
18-9 4108.528 Screw, #10-32 x 1" 3
18-10 4108.379 Steel Ball (1/4" Dia.) 1
18-11 4102.141 Pressure Relief Spring 1
18-12 4102.133 Adjusting Screw 1
18-13 4102.125 Plug 1
18-14 4109.708 Output Filter 1
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
18-15 4108.528 Screw, #10-32 x 1" 6
18-16 4101.156 Elbow, 90˚ (Barb Fitting) 1
18-17 4101.200 Blade 4
18-18 4108.588 Screw, #10-32 x 5/8" 2
19 4103.685 Fan Guard 1
20 4108.486 Hex locknut 2
21 4101.152 Bushing (wires) 2
22 4105.287 Power Line RFI Filter 1
23 4105.195 Lower Shell 1
24 4104.170 Clip Nut 6
25 4106.179 ON/OFF Switch 1
26 4104.336 Switch Cover 1
27 4110.133 Screw, #10-32 x 3/4" 1
28 4109.633 Rubber Airline 1
29 4105.508 Fuel Line 1
30 4110.195 Wire Assembly (red) 1
31 4100.541 Rubber Bushing 1
32 4103.875 Fuel Filter Assembly 1
33 4110.609 Electronic Ignitor 1
34 4108.510 Screw, #10-16 x 3/4" 2
35 4106.110 Terminal Board 1
36 4110.571 Rivet 1
37 4103.891 Fuel Tank Cap 1
38 4104.196 Flame-Out Control 1
39 4100.643 Fuel Tank 1
40 4104.183 Side Cover 1
41 4110.134 Nut, #10-32 3
42 4109.592 Hex Nut 1
43 4101.151 Bushing 1
44 4110.610 Vinyl Foam Gasket 1
45 4100.527 Lock Washer, #10 2
PARTS AVAILABLE - NOT SHOWN
4105.292 Filler Neck Screen 1
4110.138 Tradename Decal 2
4110.196 Combustion Chamber
Ground Wire 1
4110.604 Decal Package 1
PARTS LIST
70,000 BTU/HR MODEL
**Not available as an assembly, order parts separately.
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
PARTS LIST
70,000 Btu/Hr Model
