4110.607
21
21
**Not available as an assembly, order parts separately.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 4104.006 Upper Shell 1
2 4109.590 Screw/Lockwasher, 1/2" 8
3 4100.641 Combustion Chamber 1
4 4103.537 Photocell Bracket 1
5 4103.552 Photocell Assembly 1
6 4100.632 Drain Plug 1
7 4103.529 Screw, #6-32 x 3/8" 2
8 ** Burner Head Assembly 1
8-1 4103.898 Nozzle 1
8-2 4100.525 Nozzle Seal Washer 2
8-3 4100.533 Nozzle Seal Spring 1
8-4 4101.622 Nozzle Seal Sleeve 1
8-5 4105.187 Burner Head Body 1
8-6 4104.118 Barb Fitting 2
8-7 4101.846 Spark Plug 1
8-8 4100.526 Wave Spring Washer 1
9 4110.124 Screw/Lockwasher, 1/2" 13
10 4104.156 Air Line 1
11 4110.032 Fuel Line 1
12 4105.062 Fan 1
13 ** Motor and Pump Assembly 1
13-1 4100.562 Motor with capacitor 1
13-2 4101.532 Pump Body 1
13-3 4108.590 Screw, #10-32 x 3/4" 2
13-4 4108.635 Insert 1
13-5 4103.441 Rotor 1
13-6 4101.325 End Pump Cover 1
13-7 4101.358 Intake Filter 1
13-8 4108.643 End Filter Cover 1
13-9 4108.379 Steel Ball (1/4" Dia.) 1
13-10 4102.141 Pressure Relief Spring 1
13-11 4102.133 Adjusting Screw 1
13-12 4102.125 Plug 1
13-13 4108.528 Screw, #10-32 x 1" 4
13-14 4101.341 Output Filter 1
13-15 4108.536 Screw, #10-32 x 1 1/8" 6
13-16 4101.333 Lint Filter 1
13-17 4104.118 Barb Fitting 1
13-18 4101.666 Blade 4
14 4103.695 Fan Guard 1
15 4150.533 Rubber Bumper 2
16 4103.850 Edge Liner 1
17 4110.186 Motor Bracket 1
18 4100.527 Lock Washer, #10 2
19 4110.134 Nut, #10-32 3
20 4108.486 Hex locknut 2
21 4110.609 Electronic Ignitor 1
22 4108.510 Screw, #10-16 x 3/4" 2
23 4106.110 Terminal Board 1
24 4110.571 Rivet 1
25 4101.112 Bushing 1
26 4101.112 Bushing 1
27 4101.232 Bushing 2
28 4110.070 Button Plug 1
29 4105.287 Power Line RFI Filter 1
30 4108.126 Lower Shell 1
31 4104.170 Clip Nut 8
32 4110.133 Screw, #10-32 x 3/4" 1
33 4100.630 Fuel filter 1
34 4100.541 Rubber Bushing 1
35 4104.121 Fuel Line 1
36 4110.149 Fuel Tank 1
37 4103.891 Fuel Tank Cap 1
38 4110.195 Wire Assembly (red) 1
39 4104.196 Flame-Out Control 1
40 4150.528 Strain Relief Bushing 1
41 4110.563 Power Cord 1
42 4104.183 Side Cover 1
43 4110.041 Vinyl Foam Gasket 2
44 4104.336 Switch Cover 1
45 4109.592 Hex Nut 1
46 4110.164 Wire Assembly (black) 2
47 4106.179 ON/OFF Switch 1
PARTS AVAILABLE - NOT SHOWN
4105.292 Filler Neck Screen 1
4110.138 Tradename Decal 2
4110.196 Combustion Chamber
Ground Wire 1
4110.606 Decal Package 1
PARTS LIST
150,000 BTU/HR MODEL
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
PARTS LIST
150,000 Btu/Hr Model
To Next Page
