CONTROL BOARD
1. Commutator
2. Room thermostat
3. Burner
4. Fuel tank
5. Limit thermostat
6. Fan
7. Heat exchanger
8. Combustion chamber
9. Adjustable air head
5
3
2
1
4
6
7
8
9
