MASTERBLEND MASTERFORCE - PARTS BREAK DOWN (MF 502 H)

12
MASTERFORCE
MasterBlend (800) 525-9644
PARTS BREAK DOWN
MF 502H
Ref # Part # Description
38 420400 Heater
40 7204001 502 HVAC Motor 2 Stage 120V
47 7404001 Prime Valve Hose
48 721123 Pulse Hose 20” 1/4m x 1/4m
50 740423 MF Hose 1 HP Bypass
51 721221 Pulse Hose 20” 3/8m x 1/4f
52 740219 Axial Fan
53 721113 Power Prime Valve
54 715022 500 Regulator
55 719002 Pressure Gauge
61 721304 Pumptec 207/m53 motor
52 50 61 51
17 53 5447 48 48 39 55
40
