MASTERBLEND MASTERFORCE - PARTS BREAK DOWN (MF 1203)

11
MASTERFORCE
MasterBlend (800) 525-9644
PARTS BREAK DOWN
MF 1203
Ref # Part # Description
17 700101 Q.D. 1/4” Female - Brass
40 720414 1203 Vac Motor - 3 Stage 120V
7204001 1203 Vac Motor - 2 Stage 120V
41 740405 MF Vac Manifold
42 740407 MF Recovery Tank Mount
43 740209 Vac Gasket
44 740043 Vac Motor 2” Intake Flange
47 740195 Prime Valve Hose
50 740423 MF Hose/HP Bypass
51 721221 Pulse Hose 20” 3/8m x 1/4F
52 740219 Axial Fan
53 721113 Power Prime Valve
56 721402 Motor 1.5 HP
57 721401 Hypro 53226 - H Pump
58 715011 Pressure Unloader
59 719003 Pressure Guage 2000 PSI
60 721122 Pulse Hose 22” 3/8m x 3/8f
50 52 56 60
47
57 60
51
17
53 58
59
41 40 44 43
42
