OVERVIEW
UK
3
1 OVERVIEW
1.1 HOB APPLICATION
This gas-electric hob is intended for domestic cooking only. It must not be used for any other purpose.
1.2 TECHNICAL DATA
Table 1
2MIE-4GLS X
2MIE-4GLS B
Total height
90
Width
590
Overall
dimensions [mm]
Depth
515
Rated supply voltage
230V~ 50 Hz
AUX burner 1,0 kW
SR burner 1.75 kW
Gas
burners
R burner 3,0 kW
Электроподжиг горелок
Flame failure protection
Plates HOBS are made in different colours. The following letter symbols are used for different colours: X – inox;
B – white; A – anthracite.
1.3 HOB MODELS
Fig. 1
1.4 SAFETY GUIDELINES
The gas burners, electric plate HOT PLATE, grates, pots and pans become hot when hob is in use.
Handle with care to avoid burns. Pay special attention to children.
When using the drawer under the hob, do not keep flammable or hot-sensitive objects in it.
