RESET
OFF
Recovery
System
DO NOT fill tank more
than 80% of capacity!
Approved
Recovery
Tank
Figure 2
Float Switch
Cable
BLUE
YELLOW
RED
Oil
Drain
Port
80%
YELLOW
Low SideLow Side
High Side
Inlet Filter
Sightglass
Moisture
Indicator
To connect yellow hose from
manifold to the recovery, use
provided adapter.
For replacement parts and/or service contact Mastercool Inc., 1 Aspen Drive, Randolph, NJ 07869.
Phone: 973-252-9119
RECOMMENDED PARTS
Product Part #
30 lb DOT Tank with Float Switch and Left Hand Thread Fittings 62011-LH
Replacement Filter Dryer 69500-DR
Float Switch Cable 6533-01-A
Low Side R1234yf Coupler 83934
69390-INST
1 Aspen Drive • Randolph, NJ 07869
phone: 973-252-9119 • fax: 973-252-2455
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
