WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of any
other parts may create a safety hazard or cause damage to the impact wrench.
Any attempt to repair or replace electrical parts on this impact wrench may create a safety hazard unless
repairs are performed by a qualied technician. For more information, call the Toll-free Helpline, at
1-800-689-9928.
Always order by PART NUMBER, not by key number.
24
PARTS LIST
Key # Part # Part Name Qty
19 3150070079 Gear box 1
20 4010010084 600-2RS bearing 1
21 1010180009 Rotor 1
22 3150140006 Carbon brush cap 2
23 3150060015 Brush holder 2
24 1230010030 Carbon brush 2
25 2030070027 Brush holder support 1
26 4010010053 607-2RS bearing 1
27 1020180008 Stator 1
28 3022280004 Enclosure 1
29 3120030017 Direction setting button 1
30 1061010002 Switch 1
31 4030010106 ST3.9X19 8
32 4030010098 ST3.9X13 2
33 3140010004 Cord guard 1
34 1190030012 UL plug & cord 1
35 3140100006 Casting shell rubber 1
Key # Part # Part Name Qty
1 4030010114 ST3.9X25 4
2 4040030001 Spring washer 4mm 4
3 2020050059 aluminum casting 1
4 3140020017 "O" ring 1
5 2010080012 Shaft bushing 1
6 2030020034 Washer No.1 1
7 2040040088 Outer shaft 1
8 4080070001 Steel ball 5.5 2
9 2040200002 Torsion slot 1
10 4080040001 Steel ball 4 24
11 2030020035 Washer No.2 1
12 2050060178 Torsion spring 2
13 2040050022 Inner shaft 1
14 2010010027 Planetary gear 3
15 4110050003 Pin 3
16 2030020229 Washer No.3 1
17 4010010058 6002-2RS bearing 1
18 2010090067 Inner gear ring 1
25
This Mastercraft
®
product is guaranteed for a period of three years from the date of original retail
purchase against defects in workmanship and materials, except for the following components:
a. Component A: Batteries, chargers and carrying case, which are guaranteed for a period of two
years from the date of original retail purchase against defects in workmanship and materials;
b. Component B: Accessories, which are guaranteed for a period of one year from the date of original
retail purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us with proof
of purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specication), at our option. We will bear the cost
of any repair or replacement and any costs of labour relating thereto.
These warranties are subject to the following conditions and
limitations:
a. A bill of sale verifying the purchase and the purchase date must be provided;
b. This warranty will not apply to any product or part thereof that is worn, broken or that has become
inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation,
operation or maintenance (as outlined in the applicable owner’s manual or operating instructions)
or that is being used for industrial, professional, commercial or rental purposes;
c. This warranty will not apply to normal wear and tear or to expendable parts or accessories that
may be supplied with the product and that are expected to become inoperative or unusable after a
reasonable period of use;
d. This warranty will not apply to routine maintenance and consumable items, including, but not
limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, uids, tune-ups or
adjustments;
e. This warranty will not apply where damage is caused by repairs made or attempted by others (i.e.:
persons not authorized by the manufacturer);
f. This warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless specied otherwise in writing);
YEAR
ANS
3
LIMITED WARRANTY
†
DE GARANTIE LIMITÉE
†
WARRANTY
IMPACT WRENCH 054-1216-4
IMPACT WRENCH 054-1216-4
