1
2
3
11
1. Chuck jaws
2. Chuck
3. Chuck key holes
4. Chuck sleeve
5. Hammer/drilling selection switch
6. Depth-stop gauge
7. Lock-on button
8. Chuck key
9. Chuck key strap
10. Switch trigger
11.
12. Direction-of-rotation selector
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the preceding operating instructions carefully
before using.
Auxiliary handle
KEY PARTS DIAGRAM
KEY PARTS DIAGRAM
DO NOT ALLOW FAMILIARITY WITH THE HAMMER DRILL TO CAUSE A LACK OF ALERTNESS.
A FRACTION OF A SECOND OF CARELESSNESS IS ENOUGH TO CAUSE SEVERE INJURY.
EXPLODED VIEW
EXPLODED VIEW
model no.054-2015 l contact us 1.800.689.9928
