model no. 054-2437-2 | contact us 1-800-689-9928
16
No. Part No. Description No. Part No. Description
1 5610248000 Self-Tapping Screw 20 5610024000 Self-Tapping Screw
2 3900304000 Handle Set 21 4870407000 Trigger Switch
3 3129725000 Right Fan Baffle 22 5610022000 Tapping Screw
4 2751305000 Rotor Assembly 23 4900295000
Speed Governor
Assembly
5 5610227000 Screw With Washer 24 5610280000 Self-Tapping Screw
6 2740085000 Stator 25 3131148000 Mounting Cover
7 3422254000 Dust Fan 26 3707452000 Base Plate
8 2827293000
Left Housing
Assembly
27 2827312000 Front Pulley Assembly
9 5610290000 Self-Tapping Screw 28 3660129000 Spring
10 3121034000 Timing Belt 29 3660130000 Spring
11 3131150000 Belt Cover 30 5660029000 E Ring
12 5610394000
Hexalobular Socket
Tapping Screw
31 3700183000 Washer C
13 5690196000 O Ring 32 3402685000 Adjusting Knob
14 4960025000
Carbon Brush
Assembly
33 2827294000 Mounting Assembly
15 2800023000
Brush Holder
Assembly
34 3520031000 Belt Control Plate
16 3120641000 Screw Plug 35 3704111000 Epoxy Board
17 4810002000 Power Cord and Plug 36 2490136000 Nylon String
18 3121045000 Cord Guard 37 3810037000 Belt Sanding Paper
19 3120234000 Cord Anchorage 38 2827319000 Dust Bag Assembly
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
PARTS LIST
