PACKAGE CONTENTS:
Belt sander, dust bag, 1 sanding belt (80 grit) and instruction manual
KEY PARTS DIAGRAM
2
1
3
4
5
6
No. Description No. Description
1 Auxiliary handle 5 Dust bag
2 Belt adjustment knob 6 On/off switch
3 Variable-speed dial 7 Quick release tension lever
4 Lock-on button 8 Sanding belt
KEY PARTS DIAGRAM
WARNING!
• Remove the belt sander from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the belt sander is missing or damaged, do not attach the tool to a power source or use the
tool until the part has been repaired or replaced. Failure to heed this warning could result in serious injury.
7
8
