CHARGING THE BATTERY
1. Place the cordless screwdriver near a
120 V, 60 Hz electrical outlet.
2. Insert the battery charger plug (1) into
the charger receptacle (2) in the
handle of the cordless screwdriver (3)
(Fig. 1).
3. Plug the battery charger (4) into a
120 V 60 Hz wall receptacle.
NOTES:
a) The red indicator light (5) in the handle
will turn ON, indicating the battery is being
charged.
b) The red indicator light will remain ON
until the battery is fully charged.
c) A new battery or one that is completely
exhausted should be charged for 5 hours
or until the charger shuts down and the red
indicator light goes OFF. After normal use,
a battery should be fully charged in about 3
hours.
d) If the battery does not charge properly,
check to make sure the electrical outlet is
“live” and that the temperature range in the
work area is between 0–40° C (32–104° F).
INSTALLING SCREWDRIVER BITS
WARNING: Never hold the
cordless screwdriver with fingers near
the switch while changing screwdriver
bits. Accidentally touching the switch
may start the tool and possibly cause an
injury.
1. Insert the small end of the magnetic bit
holder (1) into the collet (2) of the tool
(Fig. 2).
NOTE: Push the bit holder as far as it
will go into the collet.
2. Select an appropriate screwdriver bit
that fits the head of the screw being
driven.
NOTES:
a) Use the largest size screwdriver bit
that will properly fit the screw head.
b) Make sure the screwdriver bit is in
good condition and is neither damaged
nor worn.
3. Insert the screwdriver bit (3) fully into
the large end of the magnetic bit
holder (4).
NOTE: Make sure the screwdriver bit
is fully inserted into the magnetic bit
holder until it is held in place by the
magnet.
