MasterCraft 054-3175-8 User Manual

20V max* LITHIUM-ION CORDLESS IMPACT DRIVER - 054-3175-820V max* LITHIUM-ION CORDLESS IMPACT DRIVER - 054-3175-8
3 4
WARNING!
Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do
not, by themselves, eliminate any danger, nor are they substitutes for proper accident
prevention measures.
WARNING!
This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.
Know your tool
To operate this tool, carefully read this Instruction Manual and all labels affixed to the Cordless Impact
Driver before using. Keep this manual available for future reference.
Important
This tool should only be serviced by a qualified service technician. For more information, call the
toll-free helpline at 1-800-689-9928.
Read all instructions thoroughly
Save these instructions
General power tool safety warnings
WARNING!
Read all safety warnings and instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
SAFETY GUIDELINES
MOTOR 20V DC
NO-LOAD SPEED 0–2500 RPM
IMPACT RATE 0–3200 BPM
COLLET CAPACITY Hex 1/4" (6.35 mm)
MAX. TORQUE 1400 in-lb
TOOL WEIGHT (WITHOUT BATTERY) 2 lb 12 oz (1.22 kg)
BATTERY TYPE Lithium-Ion
BATTERY VOLTAGE 20V max* DC
CHARGE INPUT 120V, 60 Hz AC only
OPTIMUM CHARGING TEMPERATURE 0–40°C (32–104°F)
*Maximum battery voltage without workload; with workload nominal voltage is 18V.
TECHNICAL SPECIFICATIONS

MasterCraft 054-3175-8 Specifications

General

Brand	MasterCraft
Model	054-3175-8
Category	Impact Driver
Language	English
