OPERATING INSTRUCTIONS
BENDING PLASTIC TUBE (See Fig. C)
WARNING: Protect hands from heat.
Choose the hook nozzle (10) and fit over the nozzle (1). Turn
the gun upside down and place on its clip stand so that it is
resting on a secure bench with the nozzle pointing upwards.
To avoid buckling or kinking the tube, fill the tube with dry
sand and seal at both ends. Heat the tube evenly by moving
from side to side and bend to required shape.
