MasterCraft 055-0216-8

headline bars
45
PARTS LIST
No. Part Number Description Qty.
1 2.06.006
Clamp Ø7 × Ø1
1
2 24.070030.00 Hole, Breather Tube 1
3 2.05.001
Clamp Ø8 × 6.5
2
4 152.070014.06 Pipe, Reversal Valve, 730 mm 1
5 122.070100.09 Fuel Tank Cap 1
6 122.070300.03 Fuel Filter 1
7 24.070800.00 Reversal Valve 1
8 1.819.0510
Screw M5 × 10
2
9 152.072000.02 Fuel Meter Assembly 1
10 1.5789.0620.1
Flange Bolt M6 × 20, Black
4
11 1.93.06 Lock Washer Ø6 4
12 2.03.004.1
Flat Washer, Ø24 × Ø6.5 × 1.5, Black
4
13 122.070015.01 Mount Vibration, Fuel Tank 4
14 152.071000.54.21 Fuel Tank, 23.1L, Blue 1
15 122.070400.05 Fuel Valve 1
16 2.06.007
Clamp Ø8 × b6
2
17 152.070011.07 Fuel Pipe, 195 mm 1
18 45.090006.20 Holder, Air Cleaner 1
19 1.6177.1.06 Lock Nut M6, Flange 2
20 1.6177.1.08 Lock Nut M8, Flange 10
21 46.100001.07 Gasket, Exhaust 1
22 46.101000.12.2 Muffler Assembly 1
23 1.16674.0820
Flange Bolt M8 × 20
2
24 152.190300.00 Carbon Brush Assembly 1
25 122.190004.01 Pinch, Carbon Brush 1
26 1.93.05 Lock Washer Ø5 2
27 1.9074.15.0520
Bolt/Washer Assembly M5 × 20
1
28 122.190400.00 Terminal Block 1
29 152.190003.00.21 Generator End Cover, Blue 1
30 1.16674.0512.2
Flange Bolt M5 × 12
3
31 1.9074.17.0516
Screw/Washer Assembly M5 × 16
2
32 1.97.1.05 Washer Ø5 2
33 1.16674.0516
Flange Bolt M5 × 16
2
34 153.190200.03 AVR 1
35 152.190002.00 End Housing 1
36 2.08.096
Flange Bolt/Washer Assembly M6 × 149
4
37 2.08.097
Bolt M5 × 184
2
