model no. 055-0216-8 | contact us 1 800 689-9928
46
SPECIFICATIONS
No. Part Number Description Qty.
38 1.6175.05 Nut M5 2
39 151.191002.15 Stator Cover 1
40 151.191200.15
Stator Assembly, Al, Ø190 × 110 mm, CSA
1
41 2.08.095
Flange Bolt/Washer Assembly M10 × 235
1
42 151.191100.15
Rotor Assembly, Al, Ø190 × 110 mm, CSA
1
43 152.192300.01 Air Guide 1
44 1.5789.0608
Flange Bolt M6 × 8
2
45 152.190005.00 Rubber, Fore-Cover, A 1
46 152.190005.01 Rubber, Fore-Cover, B 1
47 46.605.21 Engine, 389cc 1
48 1.5789.0612
Flange Bolt M6 × 12
1
49 5.1900.029 Grounding Line 150 mm 1
50 1.862.06 Lock Washer Ø6, Toothed 1
51 1.97.1.06 Washer Ø6 2
52 1.62.06 Butterfly Type Nut M6 1
53 65299.0.8.2
Frame, 689 × 536 × 600
1
54 1.5789.0835
Flange Bolt M8 × 35
2
55 1.93.08 Lock Washer Ø8 2
56 2.03.040
Washer Ø8 × Ø24 × 3
2
57 152.201200.00 Motor Mount 2
58 152.200702.02 Cover, Handle 1
59 152.200701.02.2 Handle 1
60 152.200703.03 Pin, Handle 2
61 1.894.1.08 Circlip Ø8 2
62 152.200703.04 Pin, Handle 2
63 11.110008.00 Pin "R" Shape 2
64 1.6177.1.10 Lock Nut M10, Flange 2
65 152.201200.03 Motor Mount 1 1
66 122.201501.25.1
Pin Roll, Wheel, Ø16 × Ø10 × 107, Black
2
67 152.201701.09.2 9 1/2” (24.1 cm) Wheel, PU, Black 2
68 2.16.001.1
Pin Ø2 × 33, "R" Shape , Black
2
69 152.201200.04 Motor Mount 2 1
70 1.5789.0816
Flange Bolt M8 × 16
2
71 152.200002.01.2 Support Leg 84 mm 1
72 152.201400.00 Rubber, Support 2
73 1.5789.0825
Flange Bolt M8 × 25
2
74 1.9074.3.0510 Bolt/Washer Assembly M5×10 2
75 1.6177.1.05 Nut M5 2
76 9.1000.150 Battery 12 V 15 Ah 1
