47
No. Part Number Description Qty.
77 152.200904.00 Pinch, Rubber 1
78 5.1900.125 Wire, to SAE Motor 1
79 152.200013.02.3 Jacket, Wire, Red 2
80 152.200013.02 Jacket, Wire, Black 1
81 5.1900.126 Wire, to SAE Battery 1
82 152.200013.03 Sleeve, Connector 1
83 152.279.1.2 Control Panel, Black 1
84 5.1000.001.3 Ignition Switch, Red 1
85 5.1430.008.99 Intelligauge 1
86 5.1870.003 Receptacle Cover, Receptacle L14-30R 1
87 5.1120.026 Receptacle L14-30R, CSA 1
88 5.1240.923 23 A Circuit Breaker, Double Pole, CSA 1
89 1.9074.4.0306.1
Screw/Washer Assembly M3 × 6, Black
4
90 5.1870.006 Receptacle Cover, Receptacle L5-30R 1
91 5.1120.023 Receptacle L5-30R, CSA 1
92 5.1120.027 Receptacle 5-20R, CSA 2
93 5.1870.008 Receptacle Cover, Receptacle 5-20R 2
94 2.08.171.1
Flange Bolt M6 × 12, Black
4
95 5.1810.000 Over Voltage Protector, CSA 1
96 1.818.0514
Screw M5 × 14
2
97 5.1800.000 Rectifier 1
98 5.1210.920 20 A Circuit Breaker, Push Button, CSA 2
99 5.1870.014 Circuit Breaker Cover, Push Button 2
100 1.6177.1.04.1 Lock Nut M4, Flange, Black 8
101 100687.21.10 Wire Assembly 1
102 152.210002.42 Control Box, CSA 1
103 1.9074.1.0538.2
Bolt/Washer Assembly M5 × 38
3
104 152.210003.01 Wire Jacket, Control Box 1
105 5.1320.24 Conduit, Plastic, 155 mm, CSA 1
106 152.210003.03 Plug, End Cover, CSA 1
107 100687.21 Control Panel Assembly 1
108 9.1700.009 Smart Charger, SAE 1
SPECIFICATIONS
