49
ENGINE PARTS LIST
No. Part Number Description Qty.
1 21.061300.01 Handle, Recoil, Soft, Black 1
2 1.5789.0608
Flange Bolt M6 × 8
1
3 46.061100.03.2 Cover, Recoil Starter, Black 1
4 45.060005.00 Spring, Recoil Starter 1
5 45.061102.00 Reel, Recoil Starter 1
6 2.10.003.1
Rope Ø4 × 1550, Black
1
7 45.060003.00 Spring, Ratchet 2
8 45.060002.00 Starter Ratchet, Steel 2
9 45.060009.00 Spring, Ratchet Guide 1
10 45.060007.00 Ratchet Guide 1
11 45.060008.00 Screw, Ratchet Guide 1
12 1.5789.0612
Flange Bolt M6 × 12
12
13 2.05.005 Clamp Ø6 2
14 46.080100.01.21 Fan Cover, Blue 1
15 2.02.007
Nut M16 × 1.5
1
16 1.5789.0629
Flange Bolt M6 × 29
4
17 45.060001.00 Pulley, Starter 1
18 46.123000.01 Ignition Coil 1
19 45.080001.00 Cooling Fan 1
20 46.120100.04 Flywheel 1
21 2.11.007
Oil Seal Ø35 × Ø52 × 8
2
22 2.05.050 Wire Clip, 100 mm 1
23 152.070031.01 Sheath, Wire 1
24 2.03.023
Washer Ø12.5 × Ø20 × 2, Drain Bolt
2
25 46.030100.04 Crankcase 1
26 45.127000.02 Oil Level Sensor 1
27 1.5789.0615
Flange Bolt M6 × 15
2
28 1.276.6202 Bearing 6202 2
29 47.050006.00 Weight Balancer 1
30 45.050100.14 Crankshaft 1
31 46.030008.00 Gasket, Crankcase Cover 1
32 2.04.001
Dowel Pin Ø9 × 14
2
33 46.080600.00 Air Guide, Right Side 1
34 1.276.6207 Bearing 6207 1
35 46.031000.01.1 Oil Dipstick Assembly, Black 1
36 45.030007.00 Cover, Crankcase 1
37 1.5789.0840
Flange Bolt M8 × 40
7
38 2.03.021.1
Washer Ø6.4 × Ø13 × 1, Black
1
SPECIFICATIONS
