SPECIFICATIONS
No. Part Number Description Qty.
39 45.110013.00 Shaft, Governor Gear 1
40 45.110100.00 Gear, Governor 1
41 21.110011.00 Clip, Governor Gear 1
42 45.110012.00 Bushing, Governor Gear 1
43 47.050200.00 Connecting Rod 1
44 46.050005.00 Piston 1
45 2.09.004
Circlip Ø21 × Ø1
2
46 45.050003.00 Pin, Piston 1
47 46.050303.00 Ring, Oil 1
48 46.050302.00 Ring, Second Piston 1
49 46.050301.00 Ring, First Piston 1
50 2.04.004
Dowel Pin Ø12 × 20
2
51 46.030009.01 Gasket, Cylinder Head 1
52 46.080400.00 Air Guide, Lower 1
53 46.010100.00 Cylinder Head 1
54 2.01.010
Stud Bolt M8 × 35
2
55 2.15.002(F6RTC) Spark Plug F6RTC 1
56 2.08.014
Flange Bolt M10 × 80
4
57 46.020002.00 Gasket, Cylinder Head Cover 1
58 46.021000.00 Cover, Cylinder Head 1
59 45.020001.02 Breather Tube 1
60 45.020100.00 Bolt, Cylinder Head Cover 1
61 2.08.039
Drain Bolt M12 × 1.5 × 15
1
62 46.041000.00 Camshaft 1
63 45.040013.00 Lifter, Valve 2
64 45.040002.00 Valve, Intake 1
65 45.040006.00 Valve, Exhaust 1
66 46.040005.00 Push Rod 2
67 45.040015.00 Retainer, Valve Spring 2
68 45.040017.00 Oil Seal, Valve 2
69 45.040003.00 Spring, Valve 2
70 23.040010.00 Bolt, Rocker Arm 2
71 45.040001.00 Retainer, Intake Valve Spring 1
72 45.040007.00 Retainer, Exhaust Valve Spring 1
73 45.040008.00 Rotator, Exhaust Valve 1
74 46.040004.00 Guide Plate, Push Rod 1
75 46.040016.00 Shaft, Rocker Arm 1
76 46.040201.00 Retainer, Rocker Arm 1
77 46.040009.00 Rocker Arm, Intake Valve 1
