51
No. Part Number Description Qty.
78 46.040018.00 Rocker Arm, Exhaust Valve 1
79 1.97.1.06 Washer Ø6 2
80 22.040012.00 Screw, Valve Adjustment 2
81 1.6177.1.06 Flange Nut M6 2
82 21.040021.00
Nut M6 × 0.5, Lock
2
83 2.01.008
Stud Bolt M6 × M8 × 105
2
84 46.130002.20 Gasket, Insulator 1
85 45.130001.00 Insulator, Carburetor 1
86 46.130003.20 Gasket, Carburetor 1
87 46.131000.20 Carburetor 1
88 46.130004.20 Gasket, Air Cleaner 1
89 1.6177.06 Flange Nut M6 3
90 46.091100.03 Base, Air Cleaner 1
91 45.091002.20 Seal, Air Cleaner 1
92 45.091001.20 Separator, Air Cleaner 1
93 45.091003.20 Element, Air Cleaner 1
94 46.091200.04 Cover, Air Cleaner 1
95 45.110001.00 Shaft, Governor Arm 1
96 2.03.019
Washer Ø8.2 × Ø17 × 0.8
1
97 2.11.006
Oil Seal Ø7 × Ø14 × 5
1
98 45.110008.00 Pin, Shaft 1
99 45.110003.00 Arm, Governor 1
100 2.08.040
Bolt M6 × 21, Governor Arm
1
101 45.110006.00 Rod, Governor 1
102 45.110005.00 Spring, Throttle Return 1
103 45.110007.00 Spring, Governor 1
104 46.080300.20 Air Guide, Upper 1
105 46.131017.20 Standard Main Jet 1
106 46.131017.20.01 Altitude Main Jet /
107 46.091000.03.2 Air Cleaner Assembly 1
108 46.061000.03.2 Recoil Assembly 1
109 46.040200.00 Rocker Arm Assembly 1
110 46.010000.00 Cylinder Head Assembly 1
111 1.6177.1 Flange Nut M5 6
112 45.030006.00 Plate, Coil 1
113 45.121000.00 Coil, Charging 1
114 1.5789.0835
Flange Bolt M8 × 35
2
115 45.125100.00 Starter Motor Assembly 1
116 45.125200.03 Relay, Starter, Three Gear 1
