MasterCraft 055-4504-8

No.
63
64
65
66
67
68
69
70
Qty
1
1
1
1
1
1
1
1
Description
Belt
Switch box
Printed circuit board
Rotation label
Flat washer 7
Nut M7
Adjustable knob
Switch fix plate
No.
71
72
73
74
75
76
77
78
Qty
1
2
1
1
1
1
1
1
Description
Overload label
Tapping screw ST3.5X12
Overload protector
Switch
Push-out rod
3mm Hex key
Wrench
4mm Hex key
model no. 055-4504-8 | contact us 1-800-689-9928
25
PARTS LIST
24
PARTS LIST
PARTS LIST
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Qty
9
9
1
1
1
1
2
1
2
1
1
1
1
2
2
2
1
2
1
1
1
1
2
2
2
1
1
1
2
2
2
Description
Screw M4x8
Flat washer 4
Cover
Nut
Pulley
Screw M5x10
Bearing 6004-2Z
Power cable
Retainer 42
Headstock
Spindle
Faceplate
Spur centre
Hex bolt M4
Compression spring
Handle
Jointer
Screw M4x14
Tool rest
Tool rest support
Eccentricity shaft (A)
Retainer (B)
Bolt
Handle
Compression spring
Screw M4
Shaft sleeve
Threaded rod (A)
Compression spring
Side block
Nut M8
No.
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
Qty
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
4
4
4
1
2
3
1
3
1
1
Description
Cap centre
Bearing 608
Cap centre rod
Tailstock
Screw M6x10
Screw M6x10
Tailstock spindle
Nut M6
Wheel
Handle
Screw
Handle cap
Eccentricity shaft (B)
Threaded sleeve
Threaded rod (B)
Plate
Hex bolt M6x16
Spring washer 6
Flat washer 6
Motor
Fix plate
Flat washer 5
Spring washer 5
Screw M5x12
Pulley
Hex bolt M8x30
Spring washer 8
Hex bolt M8x40
Flat washer 8
Tool bed
Clip
