A Bench jointer (assembled)
B Fence with limited block and fence assembly
C Fence mounting bracket
D Fence sliding bracket
E Cutterhead guard
F Rubber feet
G Lever with M6 flat washer and special nut
H Push blocks
I Flat washer M6
J Socket head cap screws M6 x 35
K Socket head cap screws M8 x 45
L Adjustment tool
M Wrench
N 5 mm Hex key
O Manual
A
E
J K L M N O
F G H I
B C D
UNPACKING
Carefully unpack the bench jointer and all of its parts, and compare them against the list below. Do
not discard the carton or any packaging until the bench jointer is completely assembled. Remove
the protective coating from all unpainted surfaces. This coating may be removed with a soft cloth
moistened with kerosene (do not use acetone, gasoline or lacquer thinner for this purpose). After
cleaning, cover the unpainted surfaces with a good quality household floor paste wax.
V. Assembly and adjustments
WARNING: IF ANY PART IS MISSING OR DAMAGED, DO NOT PLUG THE BENCH JOINTER
IN UNTIL THE MISSING OR DAMAGED PART IS REPLACED.
11
6-1/8" JOINTER
Item No.:055-5511-4
Instruction Manual
Toll-Free Helpline
1-800-689-9928
To Next Page
