NAILING OR STAPLING
1. Hold the handle firmly with the stapler
head (1) flat against the workpiece
(Fig. 7).
NOTE: It is very important that the
magazine assembly is firmly held at right
angles (90°) against the workpiece before
nailing or stapling.
2. When the magazine is held firmly
against the workpiece, the safety lock
(2) will disengage, enabling the
nailer/stapler to activate.
NOTE: The trigger switch will not activate
the nailer/stapler if the safety lock is not
disengaged.
3. Once the front of the nailer/stapler is
in the desired position, squeeze the
trigger switch (3) to drive the nail or
staple.
