PACKAGE CONTENTS
6
7
ASSEMBLY PREPARATION
1 Remove cartons, bags or foam containing the welder and accessories.
2 Check the contents with the packing list below.
2.2 Install the axle tube/bracket for the axles and wheels on the axle as shown in Fig. 2.1.
Stand the machine up and install the axle tube/bracket onto the back of panel using the screws and
washers provided. (You may want to prop the welder with wooden blocks for this step.)
ITEMNo. QTY.
ARC welder 1 unit
Handle 1 pc
1 pc
Wheel kit (axle, wheels , axle holder etc)
Support 1 pc
Fastener pack 1 pair
Operator s manual
1 pc
1
2
3
4
5
6
PACKAGE CONTENTS
ASSEMBLY
1. Tools required for assembly: 8 and 10 mm open-end wrenches .
2.2.1 Lay the machine side panel on a flat surface. Install the metal bracket support on the bottom
using two sets of screws and washers from the hardware bag. See following image.
